Description
Skyjack
- Model – SJIII 4632
- Platform Height – Elevated – 32’
- Platform Height – Lowered – 48.5″
- Overall Width – 46″
- Overall Length – 91″
- Stowed Height (Rails Up) – 88″
- Stowed Height (Rails Down) – 74″
- Platform Dimensions (Inside) – 42″ W x 84″ L
- Platform Extension – 4″
- Ground Clearance (Stowed) – 3.5”
- Ground Clearance (Raised) – 0.75”
- Wheelbase – 69”
- Overall Capacity – 1500 lbs.
- Main Platform Capacity – 1000 lbs.
- Platform Extension Capacity – 500 lbs.
- Weight – 5075 lbs.
- Gradeability – 25%
- Wind Rating – 28 mph
- Max # of Persons – 2
- 38′ Working Height
