Boom Lift 60′ working ht. (articulated) Self-Propelled

Daily Rate:

$315.00

Category:

Description

Haulotte Biljax 55XA

  • Working Height – 61′ 3″
  • Platform Height – 55′ 3″
  • Horizontal Outreach (From Centerline) – 33′ 5″
  • Horizontal Outreach (From Edge of Footpad) – 27′ 4″
  • Up an Over Height – 23′ 1″
  • Lift Capacity – 500 lbs.
  • Dimentions (Stowed) – 21′ 2″L x 5′ 8″W x 6′ 9″H
  • Wheelbase – 10′ 1″
  • Ground Clearance – 10″
  • Platform Size – 5′ X 2′ 6″
  • Outrigger Footprint – 13′ 11″ X 12′ 9″
  • Turntable Rotation – 350° Non-Continuous
  • Jib – Length – 4′ 3″
  • Jib – Vertical Motion – 150° (+70 / – 80)
  • Drive Speed – 4.75 MPH (Max)
  • Gradeability – 45%
  • Turning Radius – Inside (2WS) – 11′ 4″
  • Turning Radius – Inside (4WS) – 6′ 8″
  • Tire Size – 26 X 12 BAR LUG
  • Batteries – 4 X 6V 260 Amp-Hr
  • Engine – 31 hp Gas Kubota
  • Weight – 6000 lb.
