7′ Excavator

Kubota Mini Excavator

• Model – U17
• Engine – Kubota D902-E3
• Net Power – 17 hp
• Displacement – 3344.2 cu in.
• Fuel Capacity – 5.1 gal
• Max Digging Depth – 7.6’
• Max Digging Height -11.7’
• Max Vertical Wall Digging Depth – 6.3’
• Max Dumping Height – 8.1’
• Max Digging Radius – 153.6”
• Weight – 3814 lbs
• Blade Lift Height - 11.1”
• Max Drop Below Ground – 0.7’
• Overall Height – 7.7’
• Overall Length – 11.7’
• Overall Width - 3'3" / 4'1" (w/ tracks)
• Tail Swing Radius – 2.1’
• Crawler Length - 5.3’
• Ground Clearance – 0.5’
• Boom Swing Left - 65 °
• Boom Swing Right - 58 °
• Swing Speed – 9.1 rpm
• Travel Speed, high range – 2.6 mph
• Travel Speed, low range -1.4 mph
• Drawbar Pull – 4865 lbs
• Ground Pressure – 3.7 psi
• Shoe Size – 9.1”
